A.The roadblock machine products (FK16-J5000 type) Introduction
1、The main function of the barricade machine is to control the road vehicle passage, deter and stop the vehicle from forcing through. Our barricade machine can be used with the road gate control system, can be linked with our undercarriage scanning and undercarriage monitoring system, or can be used alone;
2、The barricade machine is specially designed for prisons, detention centers, drug rehabilitation centers and other places of supervision, with high practicality, reliability and safety; the operation, maintenance and maintenance of the barricade machine is very simple, very durable, and has received universal praise from customers since it was put on the market.
C.The characteristics of Soan AI intelligent roadblock system
1、The intelligent roadblock system is to use AI technology for radar detection and HD imaging analysis and face recognition and license plate recognition, and through comparison with the blacklist database of public security personnel and vehicles in the background, it will automatically detect illegal vehicles driven by dangerous people, and the system will quickly link up to raise the roadblock machine to forcibly stop the proposed forcible ramming vehicles, and at the same time link up to close all major entrance/exit channel gates and make high pitch broadcast alarm information and automatically call the nearby police force for support.
2、The intelligent roadblock can clearly see whether the driving speed of the vehicle is safe and low speed, the driving direction and movement trajectory, the possible target direction, the portrait comparison of the vehicle driver and occupants and the big data mining and analysis, to over-predict the danger and give the guards and related departments some time to quickly start the emergency plan.
3、The orderly passage of vehicles and personnel is controlled through intelligent roadblocks, while information is recorded for incoming and outgoing personnel and vehicles to facilitate data information preservation.
C.Hydraulic barricade machine technical parameters
The barricade machine is composed of three parts: barricade device, hydraulic transmission device and automatic inspection and control device, which can be customized according to the customer's needs.
Main technical parameters.
1、System control: PLC intelligent drive electric hydraulic
2、Passing pressure: it can pass the whole truck with less than 120 tons of container truck.
3、power supply: three-phase AC380V (control voltage 24V)
4、System power power (w): not less than 3.75KW
5、Rising time: 1-3S (adjustable)
6、Down time: 1-3S (adjustable)
7、Working temperature: -35℃~75℃ (suitable)
8、Storage environment: -35℃~75℃, rainproof, moistureproof and dustproof.
9、Material: A3 steel 20mm, 25mm thick, spray anti-rust primer.
10、Protection level of internal devices of barricade machine: IP68.
11、Color: a variety of colors (optional)
12, body specifications: (3000mm/3500mm/4000mm/4500mm/5000mm/5500mm) × width 995 × height 760mm, lifting height: 600mm (can be customized according to actual requirements)
C.Our barricade machine product characteristics:
1、Strong and durable structure, large load-bearing, smooth action and low noise.
2、Take PLC control, system operation performance is stable and reliable, easy to integrate.
3、Barricade machine and other equipment such as road gates for linkage control, can also be combined with other control equipment to achieve automatic control.
4、In case of power failure or malfunction, if the barricade machine is in a raised state and needs to be lowered, the raised barricade machine cover can be manually operated to fall back to the horizontal position to allow vehicles to pass.
5、Adopting low pressure hydraulic drive technology, the whole system is highly safe, reliable and stable.
6、Remote control device: through wireless remote control, card swipe, cell phone remote control, undercar scanning software control, computer remote visual control system (command center terminal remote control system, support Internet communication, WIFI, 3GPRS and other control methods.
1, (optional) with intelligent radar speed recognition function, the system uses intelligent radar to detect the driving speed of incoming and outgoing vehicles. Radar detects a vehicle driving, if the speed is low and constantly decelerating, combined with the permit vehicle authorization (i.e., white list) can be considered safe, only voice prompts the guard to pay attention to the door to a car, but not to linkage alarm and emergency raise the barricade machine. If the foreign vehicle is fast and rapid acceleration, as a dangerous behavior may be good to rush off, then a sharp alarm sounds, and quickly raise the barricade machine, and grasp the visual camera and video; in short, when the vehicle entering the crossing without security personnel to make release instructions before trying to force through, or the vehicle license plate number within the system blacklist, automatically pop up the anti-collision wall to intercept.
2, (optional) can automatically detect the speed of the vehicle, real-time computer software shows the speed of the vehicle, the level of danger, the image transmitted by the high-definition surveillance camera on the barricade machine is displayed in the software, the dangerous situation linked to the automatic voice alarm playback;
3、(Optional) The barricade should be equipped with diving type HD network intelligent camera, which can carry out portrait recognition and vehicle anti-rush detection on the control area, and automatic alarm linkage input and output control.
4, (optional) protection function: can be connected with detection probes, induction coils, etc., with anti-mistake pop-up function.
5, (optional) with road gates, radar speed detection, electric expansion gates and other equipment linkage function, with intelligent early warning found emergency dangerous driving behavior, automatic pop-up when punching the card, automatic shooting punching the vehicle license plate number and identification, vehicle and portrait capture reported to the command center.
6, (optional) temperature control function: alpine zone can be equipped with automatic heating thermostat system, so that the system can operate normally in low-temperature rain and snow weather conditions.
