双向路面式 防撞阻车破胎器Bi-directional road type anti-collision car tire breaker

产品介绍破胎器也可称挡车器或扎胎器,分为单向、双向二种,外观结构分坡式、嵌入式两种。由A3钢板(坡式外形类似于减速带)及钢板刀片组成,采用机电/液压/气动一体遥控装置,操作简便,安全可靠,是拦截非允许车辆及恐怖车辆通行的先进装备。是针对我国公路收费站过往车辆闯岗逃逸现象而研制开发的新产品。该产品在需

在线订购

一、产品介绍
破胎器也可称挡车器或扎胎器,分为单向、双向二种,外观结构分坡式、嵌入式两种。由A3钢板(坡式外形类似于减速带)及钢板刀片组成,采用机电/液压/气动一体遥控装置,操作简便,安全可靠,是拦截非允许车辆及恐怖车辆通行的先进装备。是针对我国公路收费站过往车辆闯岗逃逸现象而研制开发的新产品。
该产品在需要执行拦截任务时,按遥控器上升键,破胎器内的钢板中的锐器迅即伸出,如车辆强行通过,轮胎将被刺破而放气,同时钢板锐器能有效阻止车轮轱辘通行而被迫停车。
拦截任务结束,按动遥控器下降键,钢板锐器迅即回位至地平面以下,转入待命状态。
该产品具有破胎、阻车双重作用,价格低廉,能部分替代防撞墙的作用。保证路管人员和单位保安人员的人生安全和国家财产安全必不可少的专用设施。

A. Product introduction

Tire breaker can also be called blocker or tire zapper, divided into two kinds of one-way, two-way, the appearance of the structure of the slope type, embedded two. By the A3 steel plate (slope shape similar to the speed bump) and steel plate blade composition, using electromechanical / hydraulic / pneumatic one remote control device, easy to operate, safe and reliable, is to intercept non-permitted vehicles and terrorist vehicles passing advanced equipment. It is a new product developed for the phenomenon of escaping from the passing vehicles at our highway toll stations.

The product in the need to carry out interception tasks, press the remote control up key, tire breaker in the steel plate sharpener quickly extended, such as vehicles forced through, the tire will be punctured and deflated, while the steel plate sharpener can effectively prevent the wheel wheel passage and forced to stop.

Interception task is over, press the remote control down button, the steel plate sharpener quickly back to the ground level below, turn into the standby state.

The product has a dual role of tire breaking, stopping the car, low price, can partially replace the role of the anti-collision wall. To ensure the safety of life of road management personnel and unit security personnel and the security of national property essential special facilities.

路面双刀破胎器 (4).png

二、使用环境条件
环境温度:-40℃~+40℃
相对湿度:95%
无路面结冰的各种路面状况。
说明:1) 这里的环境温度是考虑公路表面的温度进行的特殊设计。
      2) 路面积雪、路面积水等条件下都能够正常工作。

B.The use of environmental conditions

Ambient temperature: -40℃~+40℃

Relative humidity:        95%

Various road conditions without road icing.

Note: 1) The ambient temperature here is a special design considering the temperature of the road surface.

          2) The road surface snow, road surface water and other conditions can work normally.

路面双向破胎器 .jpg
三、产品参数

表面处理

喷防锈漆,黑黄相间或定制颜色

防护等级

IP68

机箱尺寸

800*255*650mm

设备长度(拦截宽度)

特殊尺寸可定做

设备尺寸

设备总宽:800mm / 上底:640mm,突出地面高度:50mm

承载重量

通过能力(车辆吨位):100

刀片升起高度

120mm

刀片厚度

12mm

刀片间距

120mm

运动形式

机电式

工作环境

 -40℃+70℃

升降控制

近程无线遥控/线控

控制距离

≤100M

/降时间

1S-3S(可调)

供电方式

220V-50HZ

输出功率

120W-500W

控制单元

逻辑单元控制


C.Product parameters

Surface Finish

Anti-corrosion paint, black and yellow or customized color

Protection Grade

IP68

Enclosure size

800*255*650mm

Device Length (Intercept Width)

Special size can be customized

Equipment Size

Total width of the equipment: 800mm / upper bottom: 640mm, protruding height: 50mm.

Load weight

Passing capacity (vehicle tonnage): 100 tons

Blade lifting height

120mm

Blade thickness

12mm

Blade pitch

120mm

Movement form

Electromechanical

Working environment

 -40℃+70℃

Lifting control

Proximity wireless remote control/line control

Control distance

≤100M

Lifting/lowering time

1S-3S (adjustable)

Power supply mode

220V-50HZ

Output power

120W-500W

Control unit

Logic unit control
